Specifikacija:
Proizvodjac ASUS
Procesorsko ležište (socket) AMD AM4
Cipset AMD B550
Tip memorije DDR4
Memorijski slotovi 4x DDR4
Podržane memorije 2.133MHz, 3.333Mhz (O.C.), 2.400MHz, 3.733Mhz (O.C.), 3.466Mhz (O.C.), 3.866Mhz (O.C.), 4.466Mhz (O.C.), 4.866Mhz (O.C.), 2.933MHz, 2.800MHz, 4.600Mhz (O.C.), 3.000MHz, 4.800Mhz (O.C.), 3.200MHz, 4.000Mhz (O.C.), 4.133Mhz (O.C.), 2.666MHz, 4.266Mhz (O.C.), 4.400Mhz (O.C.), 4.333Mhz (O.C.)
Maksimalna ukupna memorija 128GB
Ostale osobine Podrška za Unbuffered ECC memoriju, Dual Channel
PCI Express x16 slot 1x PCI Express 3.0, 1x PCI Express 4.0
PCI Express x1 slot 2x PCI Express 3.0
PCI slot 4
SATA prikljucci (ukupno) 4
SATA prikljucci 4x SATA 6GB/s
Ostali skladišni interfejs 2 x M.2
RAID RAID 0, RAID 1, RAID 10
Žicna mreža (LAN) 1x Realtek 1Gb Ethernet
Model Realtek RTL8111H
Broj kanala 7.1
Model Realtek ALC887/897
Napomena Audio Shielding, Jack-detection, Multi-streaming, Front Panel Jack-retasking, Premium audio capacitors, Dedicated audio PCB layers
HDMI prikljucci 1
DVI prikljucci 1x DVI-D
VGA D-sub 1
PS/2 1 (tastatura ili miš)
USB 3.2 prikljucci 4 (Tip A) Gen1, 2 (Tip A) Gen2
RJ-45 (LAN) 1
Audio 3x 3.5mm
Naponski prikljucci EATX 24pin, 1x EATX 8pin 12V
USB 3.2 1 (podrška za 2 USB 3.2 Gen 1 porta)
USB 2.0 2 (podrška za 4 USB 2.0 porta)
Audio 1x Front panel audio
Ostali prikljucci 1x CPU Fan Connector, 2x M.2 Socket 3, 1x System Panel connector, 1 x Clear CMOS jumper, 2x Chassis Fan connectors, 1 x Addresable Gen 2 Header(s), 1 x COM Port header, 4 x SATA 6Gb/s, 1 x S/PDIF Out header, 1 x SPI TPM header, 2 x Aura RGB Strip Headers, 1x CPU OPT Fan Connector, 1 x Speaker connector
Napomena Za iskorišcavanje odredenih internih konektora potrebni su dodatni bracket-i ili prikljucci na kucištu
Podržane tehnologije AURA Creator, AURA Sync, DIGI+VRM, ASUS CPU-Z, LANGuard, Overvoltage Protection, SafeSlot, Fan Xpert 2+, TurboV EVO, UEFI Bios
Format microATX
Dimenzije 244mm x 244mm
Fiksirajuci otvori 8
Pakovanje 2 x SATA 6Gb/s kabl
EAN 4718017755535
Garancija 3 godine
